  • APW Wyott HMG-2424 Cookline 24" Heavy Duty Manual Gas Griddle

APW Wyott HMG-2424 Cookline 24" Heavy Duty Manual Gas Griddle

Item #: 989669
Model #: HMG-2424
Manufacturer: APW Wyott

The gas counter top griddle with a low profile design making it ideal for use on refrigerated cabinets or counter tops. The Heavy Duty Series Griddles are designed to mix and match with the Heavy Duty Char Broilers and Heavy Duty counter top ranges.

$1,455.50
Availability

Factory Ship

 Each
Add to Cart

Description
+ -
The gas counter top griddle with a low profile design that are only 13-1/8" tall to grilling surface making them ideal for use on refrigerated cabinets or counter tops. The Heavy Duty Series Griddles are designed to mix and match with the Heavy Duty Char Broilers and Heavy Duty counter top ranges. The griddle plate is 1" thick and 24" deep polished, cold-rolled steel. Six widths are available from 24" to 72" in one foot increments. The Heavy Duty Series features high-performance, energy-efficient, 33,000 BTUH burners located every 12" with individual, operator-controlled valves and are available in two control types: manual or thermostatic. The interior combustion chamber is heavy-duty heat resistant 11- and 16-gauge steel, and is hand-welded for strength and durability. Features individual 3/4" NPT rear gas connection in natural or LP gas, pressure regulator and 4" NSF approved legs with adjustable bullet feet. Stainless steel splash guards and continuously welded to the griddle plates.
Standard Features:
  • 1" Thick Griddle Plate & 24" Deep Grilling Surface
  • Heavy Gauge, Hand-Welded, Heat-Resistant Steel Combustion Chamber
  • 33,000 BTUH Burners Every 12"
  • Up to 198,000 Total BTUH in Natural or LP Gas
  • Individual Operated Burner Valves with Manual, Thermostatic/Snap-Action Controls
  • Stainless and Aluminized Steel Exterior
  • Stainless Steel, Welded Splash Guards, Landing Ledge
  • Low Profile, Counter Top Design - Only 13-1/8" to Grilling Surface
  • Front Grease Trough, and Stainless Steel, Slide-Out Grease Pan
  • Heavy-Duty 4" NSF Approved Adjustable Chrome Legs with Bullet Feet
  • 3/4" NPT Rear Gas Connection
  • Gas Specifications: 2 Burners, 80,000 BTUH Total, 23.4 KW
  • Cooking Surface Dimensions: 24" x 24" (HxW)
  • Overall Dimensions: 15-7/32" x 24" x 33-5/16" (HxWxD)
  • CUL, UL Certified
  • 1 Year Limited Warranty
  • Model #: HMG-2424
  • Energy Star Rating: Yes
  • Hazmat: No
  • Oversize: No
  • Warranty: 1 Year Limited Parts and Labor Warranty
  • UL Approved: Yes
  • Material: Stainless Steel
  • CUL Approved: Yes
  • Each Width: 24
  • Each Height: 15.22
