APW Wyott H/D Countertop Thermostatic Gas Griddle 24" HTG-2424

APW Wyott H/D Countertop Thermostatic Gas Griddle 24" HTG-2424
Item #: 973055

Model #: HTG-2424	Manufacturer: APW Wyott

$2089.31
$4,105.00 List Price

Qty:
Each

FACTORY-SHIP

Ask a Question

Review this Item

Companion Items

		3M™ Scotch-Brite™ 3.2 Oz. Quick Clean Liq. Griddle Packets Item #: 114034
$48.52

		Johnson-Rose 4.75" Griddle Turner / Scraper Item #: 142110
$3.54

		Griddle Screen Holder Item #: 114002
$3.04

Description
Specifications
Literature
Reviews
Q & A

APW Wyott H/D Countertop Thermostatic Gas Griddle 24" HTG-2424

The HTG-2424 heavy-duty countertop gas griddle with a low profile design that are only 12-1/8" tall to grilling surface making them ideal for use on refrigerated cabinets or counter top. The Heavy Duty Char Broilers and Heavy Duty counter top ranges. The griddle plate is 1" thick (25.4mm) and 24" deep (610mm), polished, cold roll-rolled steel. Six widths are available from 24" (310mm) to 72" (1829mm) in one foot increments. The Heavy Duty Series features high-performance, energy-efficient, 40,000 BTUH burners located every 12" with individual, operator-controlled valves and are available in two control types: manual or thermostatic. The interior combustion chamber is heavy-duty heat resistant 11- and 16- gauge steel, and is hand-welded for strength and durability.
Standard Features:

Stainless and Aluminized Steel Landing Ledge and Large Capacity, Slide-Out Grease Pan
NSF Approved 4" Legs with Adjustable Feet
Stainless Steel Splash Guard
1" Thick Griddle Plate & 24" Deep Grilling Surface
40,000 BTUH Burners Every 12"
Up to 198,000 Total BTUH in Natural or LP Gas
Individual Operated Burner Valves with Manual, Thermostatic/Snap-Action Controls
Stainless and Aluminized Steel Exterior
Low Profile, Counter Top Design - Only 13-1/8" to Grilling Surface
Front Grease Trough and Stainless Steel, Slide-Pit Grease Pan
3/4" (19mm) NPT Rear Gas Connection
Gas Specifications: 2 Burners 80,000 BTUH Total, 23.4KW
Cooking Surface Dimensions: 24" x 24" (HxW)
Overall Dimensions:15-7/32" x 24" x 33-5/16" (HxWxD)
UL, CUL Certified
1 Year Limited Warranty
Model #: HTG-2424

Product Name	APW Wyott H/D Countertop Thermostatic Gas Griddle 24" HTG-2424
Short Product Description	HEAVY DUTY COOKLINE GRIDDLE, GAS, COUNTERTOP, 24" X 24", 1" THICK POLISHED STEEL GRIDDLE PLATE, THERMOSTATIC/SNAP-ACTION CONTROLS, (2) BURNERS, STAINL
Product ID	973055
Manufacturer Name	APW Wyott
Model Number	HTG-2424
Length	33.31 in
Width	24.0 in
Height	15.22 in
Weight	308.0 lb
Cross Reference ID	APW-HTG2424, HTG-2424, 973055
Hazmat	N
Oversize	N
Return To Manufacturer	Y
CUL Approved	Y
Gas Type
Material	Stainless Steel
Mfg Part #	HTG-2424
UL Approved	Y
Warranty	1 Year Limited Parts and Labor Warranty
Assembly Required

Spec Sheet

Manual
