APW Wyott 23" Single Insulated Hot Food Well, w/o Drain, HFW-1

The HFW-1 Heavy-Duty Top Mount Insulated Rectangular Drop-In Food Well designed for installation in metal or wood countertops if optional wood mounting kit is provided. Hot Food Well is designed to accommodate standard size steam table pans. Well is constructed of deep-drawn 20 gauge Type 304 stainless steel, with 20 gauge aluminized outer housing with sides and bottom fully insulated. The unit is heated by a tubular heating element shaped in serpentine fashion for even heat distribution to pan base. Element is mounted under well and secured by aluminized deflector shield for maximum efficiency. Unit standard with APW Wyott E-Z Locks on all four exterior sides for easy installation. The units feature complete UL construction including electrical conduit, bezel and control box.
Standard Features:

20 gauge Deep-Drawn Type 304 Stainless Steel Well Pans
Units May Be Used WET and DRY (Wet Use Offers Best Results)
Easy Access to Heating Elements
Thermostatic Control with 36" Capillary (Effective Length 26")
Without Drain
Holds (1) 12" x 207quot; Pan
Compact Housing - Overall Depth 8-5/16"
Large Indicating Pilot Light
Outside Dimensions: 7-3/4" x 15" x 23" (HxWxL)
Inside Dimensions: 6-1/4" x 11-7/8" x 19-7/8" (HxWxL)
Cut-Out Dimensions: 13-3/4" x 21-3/4" (WxD)
Wood Mount Kit Outside Dimensions: 16-1/2" x 24-1/2" (WxL)
Wood Mount Kit Cut-Out Dimensions: 15-7/8" x 23-7/8" (WxL)
120V / 1500W / 12.5Amps
UL, CUL, CSA, CE Certified
1 Year Limited Warranty
Model #: HFW-1

Product Name	APW Wyott 23" Single Insulated Hot Food Well, w/o Drain, HFW-1
Short Product Description	HOT FOOD WELL UNIT, DROP-IN, 120V, ELECTRIC, EZ LOCK, INSULATED, INDIVIDUAL PAN DESIGN, WET OR DRY TYPE, ONE-PAN SIZE FOR 12" X 20" PAN, CONTROL PANEL W/IND
Product ID	741682
Manufacturer Name	APW Wyott
Model Number	HFW-1
Length	0.0 in
Width	0.0 in
Height	0.0 in
Weight	24.0 lb
Cross Reference ID	APWHFW1, HFW-1, APW-HFW1, APW-HFW-1, 741682
Hazmat	N
Oversize	N
Return To Manufacturer	Y
Assembly Required
CE Approved	Y
CSA Approved	Y
CUL Approved	Y
Energy Star Rating	92.5
Ground Only	N
Material	Stainless Steel
Mfg Part #	HFW-1
UL Approved	Y
Volts	120
Warranty	1 Year Limited Parts and Labor Warranty
Min Volume Capacity
