APW Wyott HFWAT-5 Top-Mount Electric 5-Pan Drop-In Hot Food Well Unit

Item #: 347529

Model #: HFWAT-5 Manufacturer: APW Wyott

$4,354.00 List Price
Factory Ship
Add to Cart
Add to WishList

The HFWAT-5 - 72-7/8" Heavy-Duty Top mount Rectangular Drop-In Food Wells (multi-wells) designed for direct installation in metal or wood countertops by plugging directly into an existing outlet. Hot food wells are designed to accommodate standard size steamtable pans and the control box is mounted directly to bottom of unit. Well is constructed of deep-drawn 20 gauge Type 304 stainless steel, above countertop with 20 gauge aluminized outer housing with sides and bottom fully insulated. Unit is heated by a tubular heating element and designed in a "W-shape" for even heat distribution to pan base. The element is mounted under well and secure by aluminized deflector shield for maximum efficiency.
Standard Features:
  • 20 gauge Deep-Drawn Type 304 Stainless Steel Well Pans
  • Easy Access to Heating Elements
  • Compact Housing - Overall Depth 8-11/16" and 11-1/2" and 11-1/2" in Non-Control Area and 12-7/10" in the Attached Control Area
  • Without Drain
  • Holds (5) 72-7/8" x 23-7/16" Pans
  • Large Indicating Pilot Light
  • Simplified Construction Reduces Installation Time and Significantly Reduces On-Site Electrical and Plumbing Costs
  • Unitized Electrical Wiring for Single Power Hookup
  • Individual Thermostatic Controls
  • Unit Standard with APW Wyott E-Z Locks on all Four Exterior Sides for Easy Installation
  • Electric Cord and Plug for Easy Installation
  • Outside Dimensions: 12-3/4" x 72-7/8" x 23-7/16" (HxWxL)
  • Cut-Out Dimensions: 72-3/4" x 22-1/2" (WxD)
  • 208V / 4250W / 20.4Amps
  • NSF, UL Certified
  • 1 Year Limited Warranty
  • Model #: HFWAT-5
Product Name APW Wyott HFWAT-5 Top-Mount Electric 5-Pan Drop-In Hot Food Well Unit
Product ID 347529
Manufacturer Name APW Wyott
Model Number HFWAT-5
Length 23.44 in
Width 72.88 in
Height 12.71 in
Weight 118.0 lb
Cross Reference ID APW-HFWAT5, APW-HFWAT-5, 347529, HFWAT-5
Return To Manufacturer
CUL Approved
Energy Star Rating
Ground Only
Material Stainless Steel
Mfg Part # HFWAT-5
Plug Type L6-30P
UL Approved
Volts 208
Warranty 1 Year Limited Parts and Labor Warranty
NSF Approved
